Country:

Manufacturer/Brand:

Model:

Year:

Valves/Tubes:

Main Priciple:

Tuned Circuits:

Waves/Bands:

Power type and voltage:

Loudspeaker:

Power Output:

Material:

Shape:

Dimensions:

Wheight:

Price in first year of sale:

Notes:

Germany

Philips Radios – Deutschland

Uranus 54 BD733A

1953/1954

13: EF80 EC92 EF85 ECH81 EM34 EF41 EBF80 EB41 ECC40 EL84 EL84 EZ80 EZ80

Superhet with RF-stage; ZF/IF 452/10700 kHz; 3 AF stage(s)

11 AM circuit(s) 11 FM circuit(s)

Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

Alternating Current supply (AC) / 110; 125; 220; 245 Volt

2 Loudspeakers / Ø 21 cm = 8.3 inch

12 Watts

Wooden case

Tablemodel with Push Buttons

670 x 410 x 280 mm / 26.4 x 16.1 x 11 inch

18 kg / 39 lb 10.4 oz (39.648 lb)

588.00 DM

Local station button, bandwidth switchable “narrow” “medium” “wide”, output power 12 watts, three times shortwave, total 90 – 16m / 3.1 – 18 MHz, HF preamplifier only effective for the ferrite antenna, so only on MW & LW, three individually switchable LF inputs for turntables, tape recorders and televisions, side shielded, frontally rotatable ferrite antenna (‘Ferroceptor’)
Push-pull output stage, without phase inversion stage.

See also the Dutch Philips model BX732A.
