Graetz 174W

Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image...

Country:

Manufacturer/Brand:

Model:

Year:

Valves/Tubes:

Main Priciple:

Tuned Circuits:

Waves/Bands:

Power type and voltage:

Loudspeakers:

Power Output:

Material:

Shape:

Dimensions:

Wheight:

Price in first year of sale:

Notes:

Germany

Graetz, Altena (Westfalen)

UKW-Grosssuper 174W

1953/1954

8: EC92 EC92 EF41 ECH81 EM34 EF41 EABC80 EL84

Superhet with RF-stage; ZF/IF 464/10700 kHz

7 AM circuit(s) 11 FM circuit(s)

Broadcast, Long Wave, Short Wave plus FM

Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt

2 Loudspeakers

4,5 Watts

Wooden case

Tablemodel with Push Buttons

587 x 365 x 270 mm / 23.1 x 14.4 x 10.6 inch

15 kg / 33 lb 0.6 oz (33.04 lb)

418.00 DM

Turnable ferrite antenna. Economy circuit for reducing the power consumption by switching the anode voltage winding.
