AEG 4065WD

AEG 4065WD 01
AEG 4065WD 02
AEG 4065WD 03
AEG 4065WD 04
AEG 4065WD 05
AEG 4065WD 06
AEG 4065WD 07
AEG 4065WD 08
AEG 4065WD 09
AEG 4065WD 10
AEG 4065WD 11
AEG 4065WD 12
AEG 4065WD 13
AEG 4065WD 14
AEG 4065WD 15
AEG 4065WD 16
AEG 4065WD 17
AEG 4065WD 18
Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image...

Country:                                                         Germany

Manufacturer / Brand:                              AEG (Radios) Allg.Elektricitäts-Ges.

Year:                                                                1955/1956

Valves / Tubes                                               6: ECC85 ECH81 EF89 EABC80 EM80 EL84

Semiconductors                                            Tr.Gl.=Metal-rectif.

Main principle                                               Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz

Tuned circuits                                               6 AM circuit(s)     9 FM circuit(s)

Wave bands                                                   Broadcast, Long Wave, Short Wave plus FM or UHF.

Power type and voltage                            Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

Loudspeaker                                                 3 Loudspeakers

Power out                                                      4 W Material

Material                                                         Wooden case

Shape                                                               Tablemodel with Push Buttons.

Dimensions (WHD)                                    570 x 380 x 225 mm / 22.4 x 15 x 8.9 inch

Notes                                                               with KW magnifier; Chassis identical to Telefunken Operette 6.

Net weight (2.2 lb = 1 kg)                          9.1 kg / 20 lb 0.7 oz (20.044 lb)

Price in first year of sale                           319.00 DM
