Phonola Neosinto 527

Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image... Loading image...

Country:

Manufacturer/Brand:

Model:

Year:

Valves/Tubes:

Main Priciple:

Tuned Circuits:

Waves/Bands:

Power type and voltage:

Loudspeakers:

Power Output:

Material:

Shape:

Dimensions:

Wheight:

Price in first year of sale:

Notes:

Italy

Phonola SA, FIMI; Saronno (VA)

Neosinto 527 Ch=525

1940/1941

5: EF9, ECH3, 6P7, EBL1, WE54, Neon_Indicator

Superhet with RF-stage; ZF/IF 470 kHz

7 AM circuit(s)

Broadcast, Long Wave and 2 x Short Wave

Alternating Current supply (AC)

Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch

Wooden Case

Tablemodel, with any shape – general

490 x 350 x 290 mm / 19.3 x 13.8 x 11.4 inch

1’850.00 LIT

Visual Tuning Indicator pre Eye
